Schneider 1 x 2.1A USB Charger

Product Code KB31USB_AS

AvailabilityIn stock

$ 51.00
Unit price
per
Shipping calculated at checkout.
Hurry! only 0 left in stock!
Order in The Next 0 Hours 32 Minutes
We will deliver on Tuesday 08/10/2021
Request For Quote
  • 1 x 2.1A USB Charger - Aluminium Silver

    1 x 2.1A USB Charger - White (KB31USB_WE)

    2 x 2.1A USB Charger - White (KB32USB_WE)

    Main

    product or component type
    USB charger
    fixing mode
    Screw



    Complementary

    device mounting
    Flush
    device presentation
    Mechanism
    colour tint
    Aluminium silver
    surface finish
    Glossy
    surface treatment
    Untreated
    number of modules
    1 module 46 x 36.7 x 21.7 mm
    condition of use
    Room temperature
    ambient air temperature for storage
    -5…60 °C
    relative humidity
    10…90 %
    [Ue] rated operational voltage
    100/240 V AC 50/60 Hz
    integrated connection type
    1 USB port 5 V DC, maximum load current: 2.1 A
    material
    Silicone rubber: cover
    PC (polycarbonate): grid plate
    PC (polycarbonate): housing
    shape of screw head
    Cross
    number of terminals
    2 screw terminals
    clamping connection capacity
    2.5 mm² for stranded cable(s)
    2.5 mm² for flexible cable(s)
    2.5 mm² for rigid cable(s)
    1.5 mm² for stranded cable(s)
    1.5 mm² for flexible cable(s)
    1.5 mm² for rigid cable(s)
    wire stripping length
    6 mm
    product compatibility
    Power bank
    XiaoMi
    Samsung
    Apple
    Major smart phone and tablet
    HW
    HTC
    height
    87 mm
    width
    87 mm
    depth
    37.1 mm
    embedding depth
    27.3 mm
    net weight
    0.0712 kg



    Environment

    product certifications
    IEC
    CCC
    IP degree of protection
    IP20
    environmental characteristic
    Liquid soap
    Alcohol
    environmental health and issues
    Halogen free



    Offer Sustainability

    Sustainable offer status
    Green Premium product
    REACh Regulation
    REACh free of SVHC
    Yes
    EU RoHS Directive
    Toxic heavy metal free
    Yes
    Mercury free
    Yes
    RoHS exemption information
    China RoHS Regulation
    China RoHS declaration
     Pro-active China RoHS declaration (out of China RoHS legal scope)
    Environmental Disclosure
