RS Pro LED Beacon 6 Chip Lamp BA15d x2PCs

RS Pro LED Beacon 6 Chip Lamp BA15d x2PCs

SKU SKU:209298

Regular price $ 184.00 SGD
Regular price $ 184.00 SGD Sale price $ 184.00 SGD
Sale Sold out
Shipping calculated at checkout.
Finish
Voltage

21 in stock

Technical data sheets

Datasheet

Blue - 24 V AC/DC

Green - 130V

Green - 230V

Green - 24 V AC/DC

Red - 230V

Red - 24V AC/DC

White - 130V

White - 230V

White - 24 V AC/DC

*Check stock before ordering. Lead time 4 working days.*

Product Details

BA15d LEDs for Light Towers

These high-quality LED lamps from our own RS Pro brand are for use in light towers or stacking beacons. Each lamp contains 6 high intensity LEDs which have been creatively designed to provide 360° illumination.

Modular stacking beacons are an ideal choice for most industrial environments as they are visually bright and can be easily adjusted. The replacement lamps are also easy to replace removing unnecessary time and effort.

Features and Benefits

LED lamp for use in light towers (stacking beacons)
Each lamp contains 6 high intensity LEDs designed for maximum light output providing full 360° all round illumination.
24Vac/dc and 130, 230 V ac types
Full-wave bridge rectifier and Bi-polar dc connections for 24 V types
Vibration and shock proof
Low current consumption and low heat generation
Minimal inrush current

Specifications

Blue - 24 V AC/DC

Attribute Value
Voltage Rating 24 V ac/dc
Current Rating 20 mA
Light Colour Blue
Intensity 6 x 400 mcd
Lamp Base BA15d
Peak Wavelength 470 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 400mcd


Green - 130V

Attribute Value
Voltage Rating 130 V ac
Current Rating 20 mA
Light Colour Green
Intensity 6 x 525 mcd
Lamp Base BA15d
Peak Wavelength 525 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 525mcd


Green - 230V

Attribute Value
Voltage Rating 230 V ac
Current Rating 20 mA
Light Colour Green
Intensity 6 x 525 mcd
Lamp Base BA15d
Peak Wavelength 525 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 525mcd


Green - 24 V AC/DC

Attribute Value
Voltage Rating 24 V ac/dc
Current Rating 20 mA
Light Colour Green
Intensity 6 x 1000 mcd
Lamp Base BA15d
Peak Wavelength 525 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 1000mcd


Red - 230V

Attribute Value
Voltage Rating 230 V ac
Current Rating 20 mA
Light Colour Red
Intensity 6 x 200 mcd
Lamp Base BA15d
Viewing Angle 30°
Peak Wavelength 630 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 200mcd


Red - 24V AC/DC

Attribute Value
Voltage Rating 24 V ac/dc
Current Rating 20 mA
Light Colour Red
Intensity 6 x 350 mcd
Lamp Base BA15d
Peak Wavelength 630 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 350mcd


White - 130V

Attribute Value
Voltage Rating 130 V ac
Current Rating 20 mA
Light Colour White
Intensity 6 x 400 mcd
Lamp Base BA15d
Peak Wavelength X=0.31 nm, Y=3.2 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 400mcd


White - 230V

Attribute Value
Voltage Rating 230 V ac
Current Rating 20 mA
Light Colour White
Intensity 150 mcd
Lamp Base BA15d
Peak Wavelength X=0.31 nm, Y=3.2 nm
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 400mcd


White - 24 V AC/DC

Attribute Value
Voltage Rating 24 V ac/dc
Current Rating 20 mA
Light Colour White
Intensity 6 x 750 mcd
Lamp Base BA15d
Diameter 20mm
Length 42 mm
Life Hours 100000h
Number of LED chips 6
Intensity per chip 750mcd
