• LED square surface mount down light. Non-dimmable.
• Power wattage (W): 8W, 15W, 24W or 36W
• Light source: LED
• Product dimensions (mm): 8W - 121 x 121 x H42
• Product dimensions (mm): 15W - 180 x 180 x H42
• Product dimensions (mm): 24W - 230 x 230 x H45
• Product dimensions (mm): 36W - 300 x 300 x H45
• LED Color Temperature (CCK): Warm white 3000K, Cool white 4000K
• Beam angle (°): 120
• Input voltage (VAC): 220-240V
• Input frequency (Hz): 50/60Hz
• Built-in LED Driver
• Mounting method: surface mounted
• Dimmable (Yes/No): No

Luminaire Property 24W Round

Luminaire Manufacturer: VISION+LITE

Luminaire Category: LED ROUND SURFACE MOUNT DOWN LIGHT Luminaire

Description: MTZ FSS623R 24W 3000K

Lamp Catalog: 24W

Number of Lamps: 1

Luminous Width (mm): 230

Voltage: 230.3 V

Power: 22.24 W

Lamp Description: 24W 3000K

Luminous Length (mm): 230

Luminous Height (mm): 45

Current: 0.181 A

Power Factor: 0.533

Photometric Results

CIE Class: Direct

Measurement Flux: 1316 lm

Downward Ratio: 100%

Field Angle: H158.4 V158.2

Luminaire Efficacy Rating (LER): 59

Max. Intensity: 486.83 cd

Total Rated Lamp Lumens: 1316.0 lm

Efficiency: 100%

Upward Ratio: 0%

Beam Angle: H108.1 V107.9

Central Intensity: 486.7 cd

Pos of Max. Intensity: H180 V1
