USAGE AREA

PHILIPS ET-S Transformer LED 220-240V | Delight.com.sg

$ 9.50

Many In Stock

Ballast /Drivers

913710032479

P1

Add to wishlist

Specifications

General Information
Type Version
-
Lamp Type
LV Halogen
Number of Products on MCB (16A Type B) (Nom)
90
Automatic Restart
Yes
Operating and Electrical
Input Voltage
220 to 240 V
Input Frequency
50 to 60 Hz
Power Factor 100% Load (Nom)
0.98
Mains Voltage Performance (AC)
202...254V
Mains Voltage Safety (AC)
198...264V
Inrush Current Width
0.10 ms
Power Losses (Nom)
0.99 W
Inrush Current Peak (Max)
15 A
Output Voltage
11.3 V
Wiring
Connector Type Input Terminals
Screw
Color Input Terminals
Orange
Connector Type Output Terminals
Screw
Cable Length From Device to Lamp
1.0 m
Wire Striplength
8.0-9.0 mm
Input Terminal Cross Section
0.75-1.50 mm²
Output Terminal Cross Section
0.75-1.50 mm²
System characteristics
Rated Ballast-Lamp Power
15 W

Temperature
T-Ambient (Max)
50 °C
T-Ambient (Min)
-20 °C
T-Case Maximum (Max)
65 °C
Approval and Application
Approval Marks
CE marking

Product Data
Full product code
694793910315700
Order product name
ET-S 15 LED 220-240V
EAN/UPC - Product
6947939103157
Order code
913710032479
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
50
Material Nr. (12NC)
913710032479
Net Weight (Piece)
0.072 kg
